COHESION TESTER Emulsified asphalt adhesion apparatus LHNJ-III

share
WeChat
copy Link
Facebook
Twitter
LinkedIn
Pinterest
Pinterest
Brand Name BETTER UNITED
Model Number BTU-LHNJ-III
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Asphalt Bitumen Test
Price Negotiable
Consult immediately
Detail

LHNJ-III-COHESION TESTER Emulsified asphalt adhesion apparatus



Description:
This instrument is used to measure the time required for the emulsified asphalt slurry seal mixture to reach full curing, so as to determine the early opening time of traffic after the construction of emulsified asphalt slurry seal mixture. This instrument conforms to the test specification of "T0754-2011" in "JTG E20-2011" standard.


Specification：

Pneumatic
two-way cylinder
Rubber pad with hardness of
60
diameter of
28.6 × 6.4mm thick
Air pressure regulator with variable bleeder control valve to maintain constant air pressure
The two-way control valve can raise or lower the rubber base
Air pressure gauge
(0-1000Kpa)
The pressurization port can be connected with bicycle pump or air compressor to pressurize the cylinder
Torque measuring wrench
(0-6N · M)
Ring mold
(6 × 60mm，10 × 60mm)
