Brand Name BETTER UNITED
Model Number BTU-LRP
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Soil test
Price Negotiable
Consult immediately
Detail

Load ring penetrometer



Description:

Used for measuring the bearing strength and compaction degree of soils. The apparatus consists of a “T” shaped handle connected to a load ring 1 kN (100 kgf) cap., with max load, and of an extension rod with five 100 mm graduations. The 30° end cone has an area of 645 mm2 (I sq. in). Supplied complete with calibration chart.Soil Testing Equipment


Specification:

Proving Ring.250 lb. (1.1 kN) capacity
Dial IndicatorBrake type
Shaft3/4" (19 mm) diam. x 18" l. (457 mm); graduated at 6" (152 mm) intervals.
Extension Rod3/4" (19 mm) diam. x 36" l. (914 mm); graduated at 6"
(152 mm) intervals.
