Electric relative density testing apparatus
Description:
The purpose of the test instrument is to calculate It is suitable for incohesive soil particle size < 5mm and samples with particle size of 2-5mm is not more than 15% of total samples to determine maximum density and minimum void ratio to calculate the relative density.
Specification:
Metal container | Dia. 50x Height 127mm |
Compaction rammer | 1.25 kg |
Fall height of rammer | 150 mm |
Diameter of rammer | 50mm |
Compaction frequency | 32TPM |
Timing range | 0-15 minutes |
Power | 220V,120W |
Net weight | 40KG |
Dimension | 500x300x940 mm |
