CBR Mould and Accessories BS
Standards:
BS 1377:4, 1924:2
Description:
Cbr Mould and Accessories (BS Standard) Soil Testing Equipment is used for the laboratory evaluation of subgrade and subbase coarse materials in road construction.With collar and perforated baseplate.Steel mould, corrosion resistant finish, supplied with collar and perforated base plate. Soil Testing Equipment
Specification:
| Description | Weight |
| CBR Type Mould (modified proctor) / Vibrating Hammer Mould , internal dia.: 152 mm,internal height: 127mm, supplied complete with extension collar and solid base plate |
8 kg |
| C- Spanner , 2 pcs | 1 kg |
| Assembly tool for Base Plate | 1.5 kg |
| Cutting Collar | 0,50 kg |
| Compaction plug with T handle , 150 mm dia. x 50 mm height | 8 kg |
| Annular Surcharge Weight | 3 kg |
| Split Surcharge Weight | 3 kg |
| CBR Perforated Base Plate | 3 kg |
| Straightedge , 3x30x300 mm | 0,30 kg |
| Filter Paper for CBR Test No:1 x 150 mm dia. | 0,20 kg |
