Detail
KO Consolidation Apparatus
Standards:
BS 1377:5; ASTM D2435, D3877, D4546; AASHTO T216; CEN ISO/TS 17892-5
Description:
For determination Φ Static pressure coefficient of 61.8 mm soil sample. Soil Testing Equipment
Features:
Convenient operation and high accuracy
Stable speed and reliable performance
Beautiful appearance, easy to use, durable
Soil Testing Equipment
Specification:
| Specimen size | Φ 61.8mm × 40mm |
| Axial load | 6kn |
| Lateral pressure or pore pressure | 1000kPa |
| Axial displacement | 0-10mm |
| Ambient temperature | 20 ℃ ± 5 ℃ relative humidity: <85% |
| Relative error of force measuring ring | < ± 1% relative error of height: +2% |
| Axial displacement error | 0.03mm minimum division value: 0.01mm |
| The pressure chamber does not leak under the rated pressure, and the volume variable is less than 0.20ml | |
| Net weight of instrument | 6kg |
