Specimen Grinding Machine
Description:
The SCM-200 automatic double end face grinding machine is an essential main equipment for producing standard samples for mechanical testing of various non-metallic solids such as rocks, ores, and concrete. This machine works in conjunction with the core taking machine and stone cutting machine produced by our factory to process high-precision cubic or cylindrical test specimens that you need. Widely used in colleges and universities, water conservancy and hydropower, geology and mineral resources, transportation, construction and other departments. The machine consists of a base, worktable, grinding power head, variable speed transmission system, electronic control device, and other parts. The whole machine is easy to operate, with automatic feeding and stable performance. Fully comply with the standards of the Ministry of Transport (JTG E20-2011).
Specification:
Grinding power head power | 1.1KW ′ 2 units, 3000 revolutions per minute |
Workbench motor power | 100W, 170 revolutions per minute |
Grinding wheel diameter | 180～200mm |
Specification of grindable standard sample | A. Block: 50 ′ 50 ′ 50-150 ′ 150 ′ 150mm B. Cylinder:50～150mm |
Standard accuracy | A. Flatness: tolerance within 50 ± 0.05mm B. Surface finish (according to the machining roughness standard): Ra3.2 |
Automatic grinding feed rate | adjustable from 0.04 to 0.12mm |
Cooling device | connected to tap water for cooling |
Dimensions | Length 1200 , Width 1000, Height 1200mm |
Weight | 350kg |
Enter three live wires and one neutral wire | |
