Sieves Perforated Plate Sieves Round Holes Square Holes
Standard:
EN 933-2; ISO 565, 3310-1, 3310-2
Description:
High Quality Testing Sieves which are used in all types of sieve testing applications, from sampling and classification of soils, aggregates and other powdered and granular materials. Testing sieves are of the highest quality to ensure consistent fit, accurate specifications and durable construction.
Perforated Plate Sieves are supplied in 200 mm and 300 mm frame diameters in various nominal aperture sizes suitable for several applications and standards.
Receiving Pans and Lids are available with 200 mm and 300 mm diameters.
There are three materials test sives includes stainless steel,polished chrome Iron sheet and brass.
Specification:
| Ø 200 mm | Ø 300 mm |
| Nominal Aperture Size | Nominal Aperture Size |
| 125 mm | 125 mm |
| 106 mm | 106 mm |
| 100 mm (4”) | 100 mm (4”) |
| 90 mm (3-½”) | 90 mm (3-½”) |
| 80 mm | 80 mm |
| 75 mm (3”) | 75 mm (3”) |
| 63 mm (2-½”) | 63 mm (2-½”) |
| 56 mm | 56 mm |
| 53 mm (2.12”) | 53 mm (2.12”) |
| 50 mm (2”) | 50 mm (2”) |
| 45 mm (1-¾”) | 45 mm (1-¾”) |
| 40 mm | 40 mm |
| 37.5 mm (1-½”) | 37.5 mm (1-½”) |
| 31.5 mm (1-¼”) | 31.5 mm (1-¼”) |
| 28 mm | 28 mm |
| 26.5 mm (1.06”) | 26.5 mm (1.06”) |
| 25 mm (1”) | 25 mm (1”) |
| 22.4 mm (7/8”) | 22.4 mm (7/8”) |
| 20 mm | 20 mm |
| 19 mm (¾”) | 19 mm (¾”) |
| 18 mm | 18 mm |
| 16 mm (5/8”) | 16 mm (5/8”) |
| 14 mm | 14 mm |
| 13.2 mm (.530”) | 13.2 mm (.530”) |
| 12.5 mm (½”) | 12.5 mm (½”) |
| 11.2 mm (7/16”) | 11.2 mm (7/16”) |
| 10 mm | 10 mm |
| 9.5 mm (3/8”) | 9.5 mm (3/8”) |
| 9 mm | 9 mm |
| 8 mm (5/16”) | 8 mm (5/16”) |
| 7.1 mm | 7.1 mm |
| 6.7 mm (.265”) | 6.7 mm (.265”) |
| 6.3 mm (¼”) | 6.3 mm (¼”) |
| 5.6 mm (No. 3-½”) | 5.6 mm (No. 3-½”) |
| 5 mm | 5 mm |
| 4.75 mm (No. 4) | 4.75 mm (No. 4) |
| 4 mm (No. 5) | 4 mm (No. 5) |
