TC-A Pull Off Adhesion Tester
Standard:
1.ISO 4624 《Paints and varnishes-Pull-offtest for adhesion》
2.ASTM D4541 《StandardTest Method for Pull-Off Strength of Coatings Using Portable Adhesion Testers》3.ASTM D7234 《Standard Test Method for Pull-OffAdhesion Strength of Coatings on Concrete Using Portable Pull-Off Adhesion Testers》
4.GB/T 5210-2006《Paints and varnishes - Pull-off adhesion test》
5.GB/T 31586.1-2015,Evaluation and acceptance criteria for protective coating of steel structures-Part 1: Unmethod test6.JT/T 695-2007, Anti-corrosion technical conditions for the surface coating of concrete bridge structure7.JTS/T 209-2020 ,Code for anti-corrosion construction of water transport engineering structures8.DL/T 5193-2021 ,Technical regulations for epoxy resin mortar
Description:
The TC-A fully automatic adhesion tester can measure the adhesion of surface coatings on metals, concrete, and other substrates. The working principle of this instrument is to use a hydraulic system to detach a certain diameter coating on the surface of the tested substrate to measure the adhesion of the coating. The multifunctional touch LCD display screen of the tester displays the detection process of adhesion, which is displayed in MPa, kN, or Psi units. This product is designed and manufactured according to relevant international and Chinese standards, with reliable technology and stable performance.
Standard configuration list:
1. One electric digital display device
2. Quickly pull out one sleeve
3. One charger
4.20mm spindles (standard configuration)
5. One cutter
6. Six grinding pads
7. One set of adhesive
8. One certificate of conformity, one warranty card, and one instruction manual each
9. One portable instrument box
Parameters:
