Brand Name BETTER UNITED
Model Number BTU-CAT
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Non destructive test
Price Negotiable
Consult immediately
Detail

Coating Adhesion Tester



Compliant with standards：

·JGJ144-2019 Technical Specification for External Wall Insulation Engineering;

·JGJ110-2017 "Inspection Standard for Bond Strength of Decorative Bricks in Building Engineering";

·JGJ126-2000 Code for Construction and Acceptance of Exterior Wall Facing Brick Engineering;

·GB/T 5210-2006 "Paints and Varnishes - Pulling Test for Adhesion";

·TB-T2965-2011 Technical Conditions for Waterproof Layer of Railway Concrete Bridge Deck;


Description:The intelligent high-precision coating adhesion tester is mainly used for detecting coating adhesion in high-speed rail project construction. It is an essential testing instrument for various quality inspection and construction units.


Parameters:

Instrument structure
integrated
Display mode
adjustable force and strength
Measurement range
0~10.00kN/0~5MPa
Resolution
0.001kN
Peak maintenance
Yes
Data storage
500 pieces
Numerical correction
10 segment line numerical correction to improve accuracy
LCD lighting
Yes
Power supply method
High capacity lithium battery
Automatic shutdown
Yes
Hydraulic cylinder stroke
65mm
Main material
lightweight alloy
Main body weight
2.8kg
