Shore Durometer
Compliant with standards：
DIN 53505,ASTM D2240 ISO/R868,JIS R7215，GB/T531-99,GB2411-80,HG/T2489-93,JJG304-2003
Description:
The Shore hardness tester (rubber hardness tester) is widely used for measuring the hardness of rubber and plastics. It has the characteristics of simple structure, convenient use, light size, and intuitive reading. It can be carried around for handheld measurement, or installed on the same type of fixed load rack produced for fixed load measurement. This instrument complies with the JB6148-92 standard. It can be carried around for handheld measurement or installed on the matching SLX Shore hardness tester rack for use.
The Shore hardness score is divided into two types: mechanical and digital. Type A is suitable for general rubber, synthetic rubber, and soft rubber. Type C is suitable for composite rubber, leather, wax, and other materials. Type D is suitable for general hard rubber, resin, acrylic, glass, thermoplastic rubber, printed boards, fibers, etc.
Specification:
Product model | Pointer type A | Pointer O-type | Pointer type D |
Suitable material | Soft rubber | Foam class | Hard plastics |
Measuring range | 10~90HA | 10~90HC | 10~90HD |
Dial value | 0~100HA | 0~100HC | 0~100HD |
Needle stroke | 0-2.5mm | ||
Needle size | 0.79mm | 2.5mm | 0.1mm |
Product size | 80*53*25mm | ||
Product weight | 145g | ||
