Six Speed Rotational Viscometer Digital MK-SN6

share
WeChat
copy Link
Facebook
Twitter
LinkedIn
Pinterest
Pinterest
Brand Name BETTER UNITED
Model Number MK-SN6
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Drilling Fluid Test
Price Negotiable
Consult immediately
Detail

Six Speed Rotational Viscometer Digital



Description:

Mk-sn6 digital display six speed rotary viscometer is a digital display viscometer designed by our company. The shell is formed by plastic

shell. The digital six speed rotary viscometer is driven by a stepping motor, and the rotation speed is more stable; The panel keys are clearly marked and easy to operate. The high-resolution LCD screen can display the viscosity value of the test liquid and the stirring speed in real

time.During viscosity measurement, when the outer sleeve rotates at a set speed, the fluid will produce a viscous resistance, so as to measure the viscosity of the fluid. Digital rotary viscometer can be widely used in petroleum, chemical, food, medicine, cosmetics and other industries and scientific research institutions.


Specification:

1.Power supply AC220V ± 5%; 50Hz
2.Motor power: 40W
3.Motor speed: 800r / min
4.Speed range: 3, 6, 100, 200, 300, 600r / min
5.Measurement accuracy: 1-25mpa. S ± 1MPa. S (Newtonian fluid) above 25MPa. S ± 4% (Newtonian fluid)
6.Viscosity measurement range: Newtonian fluid: 1 ~ 300mpa S (F1 measuring assembly) 1 ~ 60MPa S (f0.2 measuring assembly)Non Newtonian fluid: 1 ~ 150 MPa S (F1 measuring assembly) 1 ~ 30 MPa S (f0.2 measuring assembly)
7.Shear stress 0 ~ 153.3pa (F1 measuring component) 0 ~ 30.7pa (f0.2 measuring component)
8.Measuring assembly F1 measuring assembly (f0.2 measuring assembly can be optional)
9.Size 400×180×280/620×300×490mm
10.Weight: 13.4kg/6.9kg
