Concrete Anti Splitting Fixture
Description:
The splitting tensile strength test of concrete adopts cubic or cylindrical specimens. In the center plane of the specimen, uniformly distributed pressure is applied to generate approximately uniformly distributed tensile stress in the vertical plane under external force. This tensile stress can be calculated according to elastic theory.
There are two types of concrete anti splitting fixtures. One method is to conduct a splitting tensile strength test on cylindrical standard specimens with a diameter of 150mm × 300mm (or non-standard specimens with a diameter of 100mm × 200mm). One type is a cube, which is subjected to a splitting strength test on a 150mm standard cube specimen (or a non-standard cube specimen with a side length of 100mm).
Specification:
Technical parameters of anti splitting fixture for cylindrical concrete | |
Maximum support block | 50mm × 20mm |
Width of left and right brackets | 151mm, 101mm |
Length | 305mm |
Net weight | 25Kg |
Applicable models | Universal type, can be used on universal machines and press machines produced by various factories |
Test piece size | Meet the standard cylindrical test piece with a diameter of 150mm × 300mm (or non-standard test piece with a diameter of 100mm × 200mm) |
Technical parameters of square anti splitting fixture | |
Fixture model | PL-07 type |
Dimensions (length x width x height) | 250 x 210 x 220mm |
Net weight | 14.5kg |
Applicable models | Universal type, can be used on universal machines and press machines produced by various factories |
Test piece size | meet the requirements of cube specimens with side lengths of 100mm and 150mm |
