Coating Conical Mandrel Bend Tester ZQ-II

Brand Name BETTER UNITED
Model Number BTU-ZQ-II
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Coatings Paint test
Price Negotiable
Consult immediately
Detail

Coating Conical Mandrel Bend Tester



Description:

The cone bending tester is designed according to GB / T 11185 and iso6860-84 standards to evaluate the cracking resistance or peeling resistance of coatings of paints, varnishes or related products when they are bent around the cone axis under standard conditions. The instrument makes the coating stretch under different diameters through a changing cone diameter, and can accurately evaluate the adhesion performance of the coating film.


Parameters:

Product model
ZQ-1I
Taper shaft size
big end Φ 38mm, small end Φ 3.1mm, 203mm long
Test piece size
190x110mm
Thickness of test piece
0.3 ~ 0.8mm (hard substrate) 0.3 ~ 5.0mm (soft substrate)
Overall dimension
300x120x90mm (L x W x H)
Weight
7kg
