Ceramic Flexural Testing Machine 50 kN

Ceramic Flexural Testing Machine 50 kN

Description:

The ceramic tile bending strength testing machine is manufactured in accordance with GB/T 4741-1999 "Test Methods for Flexural Strength of Ceramic Materials". It is mainly used for testing the physical and mechanical properties of various ceramic materials, such as the flexural strength, under normal temperature conditions. It refers to the maximum stress that a ceramic sample can withstand when it ruptures under a bending load or reaches a specified bending moment.

Features:

1. Precision clearance free ball screw, high rigidity, high stability gantry load frame, frame size can be customized.

2. High precision force measuring device, wide linearity, good stability, ensuring the accuracy of load measurement.

3. High speed, low vibration, maintenance free, silent AC servo motor drive system.

4. The circuit board adopts a photoelectric isolation design with strong anti-interference ability.

5. Built-in Ethernet interface; Convenient handheld controller with stop and go function; Flexible operation and random switching.

6. Various complete test fixtures for quick replacement; Optional T-table, anti rotation fixture/accessory device, environmental system, extensometer.

7. Wide testing speed of 0.001~600mm/min (customizable high-speed testing machine of 1000mm/min; 1500mm/min; 2000mm/min).

8. Fully digital closed-loop, multi-channel, multifunctional, and easy to control measurement and control software; Various standard methods (national standard, British standard, American standard, German standard, Australian standard, Japanese standard, Italian standard, Russian standard, European standard/GB, ISO, JIS, ASTM, DIN, BS, EN).

9. Automatic control, data acquisition, processing, analysis, storage, and display of the test process.

10. Automatic load holding, stress and strain control, cycle control, and self programming control are various control methods.

11. Intelligent setting of control modes, no impact between control modes, smooth switching, and stable loading and unloading.

12. Process reproduction and data reanalysis, curve amplification, comparison, and traversal; The curve can be freely zoomed in and out.

13. The control software adopts modular, open programming, and personalized design, which can be adjusted by oneself.

14. Standard module; Permission management module, test module, control module, analysis module, query module, and output module.

15. Operation tips and wizard functions.

16. Flexible Excel or Word report format, selectable, specified, sorted, individual, merged, and multi type output.

17. Network database management.

18. Automatically return after the test, intelligent, and fast.

19. Multiple protection functions: test force overload protection; Overcurrent and overvoltage protection; Safety protection in case of sample breakage; Overtemperature protection; Dry burn protection; Water shortage protection; Operation prompt wizard protection; Automatic protection after the test.

Specification:
