Air Mortar meters-B2030

Air Mortar meters-B2030

Description:

The principle of the mortar air content analyzer is based on the gas equation. When the opening and closing pressures are balanced between an air chamber that maintains a certain pressure and a container filled with the sample, the amount of pressure reduction in the air chamber when the pressures of the two containers reach equilibrium is the percentage of air content in the mortar, which is expressed on the pressure gauge as the air content in the sample.

Main technical parameters of mortar air content tester:

Pressure gauge: imported from Germany

Pressure gauge range: 0-0.1MPa

Gas content value 0-100%, can be read directly, with a reading of 0.1%

Random measuring cylinder: 25ml

Accuracy: ± 0.1%;

Size: 200mm (diameter) * 320mm;

Weight: 4kg

Capacity: 1L;
