Cleveland Open Cap Flash and Fire Point Tester Digital display

Cleveland Open Cap Flash and Fire Point Tester Digital display

1、 Applicable standards

This instrument is designed and manufactured in accordance with the national standard GB/T3536-1991 "Determination of Flash Point and

Ignition Point of Petroleum Products" (Cleveland Open Cup Method) for petroleum and petroleum product testing methods.

This instrument is also applicable to JTJ052-2000 Highway Code T0611-1993 "Asphalt Flash Point and Ignition Point Test" (Cleveland Open

Cup Method), international standard ISO-2592 test method, and American Society for Testing and Materials standard ASTMD92 test.

2、 Purpose and Scope of Application

This instrument is suitable for measuring the flash point and ignition point of viscous petroleum asphalt, coal tar pitch, and liquid petroleum asphalt materials with a flash point above 79 ℃ using the Cleveland Open Cup (COC) to evaluate construction safety.

3、 Working conditions of the instrument

Power supply: 220V ± 10% 50Hz

Rated power: 1100W

Environmental temperature: -10 ℃~50 ℃

Relative humidity: ≤ 85%

4、 Main features and technical parameters

1. LCD screen display;

2. Automatic control of heating power;

3. Automatic scanning;

4. PT100 high-precision imported sensor;

5. The heating power of the electric furnace is continuously adjustable from 0 to 1000W;

6. The heating wire is protected by a transparent quartz tube, with no open flame, explosion-proof, and fast heating speed;
